Manufactured in 2008. 10″ diameter x 48″ long tube section. Two pass 64 tubes per pass. 97.7 sq ft surface area. Carbon steel shell.
Stainless steel tubes and process side connections. Shell side MAWP: 200 PSIG at 150 degrees F. Tube size MAWP 600 PSIG at 400 degree F.
National Board number: 10546. CRN number D08735.6 (Quebec). Process inlet/outlet connections. 4″ 600# RF.
Cooling water inlet/outlet connections. 2 1/2″ NPT 3000#.

Contact us for drawing sand additional information.

NEW SURPLUS, installed but never put into service.
